Free Space Acousto-Optic Modulators
80MHz AOM Radio Frequency Drive TTL Modulation AOM Drive
Product ID: 6405
$446
80MHz AOM Radio Frequency Drive TTL Modulation AOM Drive
[Features]
Stable working performance
High frequency stability
Stable power output
Low power consumption
Note:
Lead Time: 1~3 weeks
[Specifications]
| Parameter | Unit | Value |
|---|---|---|
| Output Frequency | MHz | 80±0.01% |
| Output Power | W | 0.1~2 |
| Rising Time | ns | 10 |
| Modulation Mode | 0~3.3V/5V TTL | |
| Output Resistance | Ω | 50 |
| Operating Voltage | V | +24VDC@380mA |
